Unleash Premium Sound - Experience powerful, distortion-free amplification with 100W per channel at 8Ω and 200W per channel at 4Ω. Equipped with PFFB technology, a premium ESS 9039Q2M DAC, and TI TPA3255 amplifier chip, it delivers superior clarity, deep bass, and dynamic range for an immersive listening experience.
Sleek & Durable Aluminum Design - Built with a precision-crafted unibody aluminum chassis, this amplifier ensures maximum durability and peak performance. Its advanced thermal management system with a copper heat pipe and graphene heatsink keeps it cool under the most demanding conditions.
Seamless Integration with WiiM Streamers - Designed for perfect compatibility with WiiM Mini, Pro, Pro Plus, and Ultra, the Vibelink Amp offers low-latency, high-resolution playback for a flawless streaming and audio experience.
Pure Analog Input (no ADC conversion) - For analog purists, the direct analog input bypasses Analog-to-Digital Conversion (ADC), preserving the purest, most natural sound.
True High-Resolution Playback - Unlike standard amps, the WiiM Vibelink Amp supports variable sample rates and bit depths, preserving lossless, high-fidelity sound for streaming, FLAC, and vinyl rips. Enjoy bit-perfect 192kHz/24-bit playback via Optical and Coax inputs with zero signal loss.
Smart, Energy-Efficient Operation - 12V Trigger In & Auto Standby Mode provide hands-free convenience and power savings.
Anti-Pop Noise Design – Enjoy smooth, uninterrupted audio with advanced anti-pop noise technology. The WiiM Vibelink Amp ensures seamless transitions across variable sample rates and bit depths, eliminating unwanted pops or clicks when switching tracks, sources, or playback resolutions for a flawless listening experience.
NOTE: This device is a pure power amplifier and does not support streaming functions, unlike other WiiM devices. It delivers 60W output when using the RCA input and 100W when using a digital input.
Specifications
Power & Amplification
Output Power: 100 W per channel @ 8 Ω (stereo)
Amplifier Technology: Class D with PFFB (Post-Filter Feedback)
Total Harmonic Distortion + Noise (THD+N): ≤0.0005%
Signal-to-Noise Ratio (SNR): ≥120 dB
Frequency Response: 20 Hz – 20 kHz ±0.5 dB
Speaker Impedance Range: 3 – 8 Ω
Audio Processing
DAC: ESS 9039Q2M high-performance DAC
Bit-Perfect Playback: Up to 192 kHz / 24-bit
Dynamic Range: ≥120 dB
Pure Analog Input Path: No ADC conversion
Input & Output Options
Analog Input: 1 × RCA Stereo (Line-In)
Digital Input: 1 × Optical (TOSLINK) up to 192 kHz / 24-bit
Digital Input: 1 × Coaxial (S/PDIF) up to 192 kHz / 24-bit
Speaker Outputs: Gold-plated binding posts (banana plugs or bare wire)
12 V Trigger Input: Auto power-on with compatible devices
Auto Standby Mode: 30 or 60 minutes of inactivity
Supported Audio Formats
PCM: Up to 192 kHz / 24-bit (digital sources)
Control & Interface
Volume Control: Front-panel volume knob
LED Indicator: Three RGBW LEDs indicating source and status
Build & Design
Chassis: Premium unibody aluminum
Thermal Management: Copper heat pipe, large aluminum heatsink
Thermal Control: Precision PID temperature regulation
Cooling System: Passive, silent operation
Power & Physical
Power Input: 100–240 V AC, 50/60 Hz, 3 A max
Dimensions: 7.9 × 8.4 × 2.6 in
Dimensions: 200 × 212.5 × 66 mm
Weight: 2.05 kg (4.5 lbs)
Package Contents
User Guide ×1
Power Cable ×1
RCA Cable ×1
Optical Cable ×1
Banana Plugs ×4
