Anthem STR High-resolution Preamplifier

Skip to product information
1 of 5

STR Preamplifier (B)

Regular price $5,249.99
Sale price $5,249.99 Regular price
Color: Black


Contact Us

Please call us at 1-905-270-3440 or simply fill out the form below for ordering & more info.


STR POWER PREAMPLIFIER

Push The Power of Audio Control

The revolutionary new STR Preamplifier is based on an entirely new platform. It gives you more control and more refinements including more connection options and more advanced technology, in a single, easy-to-use component. It combines the benefits of an advanced pre-amp with the power of a processor, as well as functions like leading-edge DAC, onboard

Anthem Room Correction, customizable bass manager for mono or stereo sub outs, MM and MC phono inputs – far more features than the average preamplifier. And count on Anthem’s digital signal processing innovations to deliver a noticeably higher level of performance realism. The new STR Preamplifier drives all of your entertainment options today, and tomorrow.

Features & Functions

  • High-resolution preamplifier
  • Anthem Room Correction™ to optimize in-room response
  • Bass management for two subwoofers, in mono or stereo
  • Up-sampling of lower-resolution sources to 32-bit / 192 kHz
  • Asynchronous USB audio input supports 32-bit / 384 kHz PCM, and DSD 2.8 / 5.6 MHz sources
  • S/PDIF coaxial and optical, and balanced AES/EBU inputs
  • MM and MC phono, balanced XLR, and single-ended analog inputs
  • Analog Direct Mode
  • Graphic front panel display for easy setup navigation
  • Controllable via Ethernet, RS-232, or supplied IR remote
  • Balanced output for all channels including the two subs
  • Home Theater Bypass Mode works without having to turn power on and includes RCA/XLR input for two subs

Specifications

STR Preamplifier

Overview

  • High-resolution stereo preamplifier
  • Anthem Room Correction (ARC) for optimized in-room response
  • Bass management for two subwoofers (mono or stereo)
  • Analog Direct mode
  • Graphic front panel display for setup and navigation
  • Home Theater Bypass Mode with RCA/XLR subwoofer inputs

Digital & Analog Features

  • Up-sampling to 32-bit / 192 kHz
  • USB Audio Input: 32-bit / 384 kHz PCM, DSD 2.8 / 5.6 MHz
  • Digital Inputs: S/PDIF coaxial, optical, AES/EBU
  • Analog Inputs: MM and MC phono, balanced XLR, single-ended RCA
  • Balanced outputs for all channels including subwoofers

Control & Connectivity

  • Ethernet control
  • RS-232 control
  • IR remote control included

Dimensions & Weight

  • Dimensions (H x W x D): 3-8/9" x 17" x 14-5/6"
  • Weight: 16.8 lb

STR Stereo Power Amplifier

Amplifier Design

  • 400 W / 600 W / 800 W continuous output into 8 / 4 / 2 Ω (both channels driven)
  • Cascoded complementary feedback input stage
  • Sixteen bipolar output devices per channel
  • Multi-mono design
  • Massive toroidal transformers
  • Soft turn-on circuitry
  • Advanced Load Monitoring Technology
  • No rail fuses

Control & Operation

  • Four power on/off options
  • Graphic front panel display for power meter and status

Dimensions & Weight

  • Dimensions (H x W x D): 6-3/4" x 17" x 18-1/2"
  • Weight: 60 lb
