Anthem

Anthem MRX 740 8K AV Receiver

  • Black Anthem_mrx_740_8K_av_Receiver front view
  • Black Anthem_mrx_740_8K_av_Receiver back view

MRX 740 8K

$3,699.99
$3,699.99

In-Store Only

Contact Us

Please call us at 1-905-270-3440 or simply fill out the form below for ordering & more info.

Pure Performance, Pure Value

Anthem's MRX A/V Receivers are about maximizing audio performance that previously has been unobtainable at their respective price points. Building on the feature set of our previous models, we've added the newest version of ARC Genesis, a redesigned and more accurate calibration microphone, Anthem's Web User Interface, integrated streaming support, object-oriented audio codecs with support for up to 15.2 channels and the clean power delivery Anthem is known for with up to 140 watts per channel.

The MRX 540, 740 and 1140 are a great way to bring premium audio to any home theater or media room. Seamlessly integrate your smart TV or projector with 7 dedicated 8K HDMI inputs that support 8K/60Hz or 4K/120Hz pass-through and 2 dedicated outputs with eARC. With MRX, you can enjoy 8K quality video from all of your 8K source devices in amazing clarity.

Key Features

  • 11.2 Pre-Amplifier / 7 Amplifier Channel A/V receiver with Dolby Atmos, DTS:X and IMAX Enhanced
  • 140-watts per channel continuous power into 8 ohms
  • Includes ARC (Anthem Room Correction)
  • HDMI 2.1, HDCP 2.3 supporting 8K/60Hz or 4K/120Hz

Specifications

Anthem MRX 740

Key Features

  • Up to 11.2 pre-amplifier channels with 7 amplifier channels
  • 140 W per channel continuous power into 8 Ω
  • HDMI 2.0b with HDCP 2.2, upgradeable to HDMI 2.1 (8K)
  • Dolby Atmos and DTS:X decoding
  • IMAX Enhanced
  • ARC Genesis room correction with precision microphone
  • Amp matrixing with up to 6 re-assignable channels
  • Two paralleled subwoofer outputs
  • Independent HDMI Zone 2 output
  • Next-generation DSP platform
  • High-resolution front panel display

Audio Features

  • Processing: 11.2 channels
  • Internal Amplification: 7 channels
  • Speaker Profile Memories: 4
  • Speaker Distance Increments: 2" / 5 cm
  • Level Increments: 0.5 dB
  • Auto Subwoofer Phase and Polarity (ARC Genesis)
  • Super Sub Front setting
  • Listening Modes: Anthem Logic, Dolby Surround, DTS Neural:X, DTS Virtual:X, Stereo, All Channel Stereo, Mono, All Channel Mono

Streaming

  • Apple AirPlay
  • Apple AirPlay 2
  • Google Chromecast Audio
  • Bluetooth v4.2
  • Spotify Connect (coming soon)
  • Roon (coming soon)

Decoding

  • Dolby Atmos
  • Dolby HD
  • DTS:X
  • DTS-HD Master Audio

HDMI & Video

  • Dolby Vision
  • IMAX Enhanced
  • HDMI 2.0b & HDCP 2.2 (upgradeable to HDMI 2.1 / 8K)
  • HDMI eARC
  • 4:4:4 chroma subsampling @ 4K60 (18.2 Gbps)
  • HDR, HLG, BT.2020 color gamut
  • 4K 50/60 switching
  • Dual HDMI outputs
  • Zone 2 HDMI output
  • Standby pass-through

Preamplifier Specifications

  • Maximum Output (<0.1% THD): 5.2 Vrms, 7.1 Vrms
  • Frequency Response: 20 Hz - 30 kHz (±0.2 dB)
  • THD+N (2 Vrms output): -100 dB
  • S/N Ratio (2 Vrms output, IEC-A): 110 dB
  • Preamplifier + Amplifier SNR (1 W output): 91 dB (ch 1-5), 86 dB (others)
  • Speaker Impedance: Compatible with 4 Ω or higher

Power Output (1% THD, Two Channels Driven)

  • Channels 1-5 into 8 Ω: 140 W
  • Channels 1-5 into 6 Ω: 170 W
  • Remaining channels into 8 Ω: 60 W
  • Remaining channels into 6 Ω: 75 W

Power Consumption

  • Typical Load: 485 W
  • Standby: 0.3 W
  • Standby (IP Control Enabled): 1.8 W
  • Standby (HDMI Bypass Enabled): 4.9 W

Dimensions & Weight

  • Height (without feet): 6" (15.24 cm)
  • Height with rackmount kit: 4U
  • Width: 17" (43.18 cm)
  • Depth (including Wi-Fi antenna, excluding power cord): 14-1/2" (36.4 cm)
  • Product Weight: 33.2 lb (15.1 kg)
  • Shipping Weight: 40.0 lb
  • Product Dimensions: 13.2" x 17" x 6.50"
  • Shipping Dimensions: 11" x 21" x 24.5"

Custom Installation & Additional Features

  • IP Control
  • RS-232 Control
  • IR Input
  • Three 12V Trigger Outputs
  • Pre-made control drivers
  • Save and load settings
  • Import and export settings
  • Anthem Web User Interface
  • Advanced Load Monitoring (ALM)
  • Over-the-air network updates and USB updates
  • Backlit remote control
